This article covers Intel Wireless-AC 9560?M.2 2230?2X2 Ac+BT Vpro (9560.NGWG.NV).

Overview

The Intel Wireless-AC 9560 (model 9560.NGWG.NV) is an M.2 2230 wireless module designed for Intel platforms featuring the CNVi interface. It combines 2x2 802.11ac Wi-Fi 5 with Bluetooth 5.0 support, achieving a maximum link rate of 1.73 Gbps. Originally an OEM component found in many business laptops and mini PCs, this module is now available for individual purchase on marketplaces like . Its key distinction is the use of Intel's proprietary CNVio bus, which offloads Wi-Fi processing to the CPU and requires a compatible Intel SoC (e.g., 8th generation Core or later). For users with compatible hardware, it offers a straightforward drop-in upgrade for integrated wireless connectivity.

Connectivity & Compatibility

The module fits into an M.2 Key E (2230) slot, but it only works with systems that have a CNVi-capable Intel SoC. Compatible CPUs include 8th-generation (Coffee Lake) and newer Core processors, as well as some Pentium and Celeron SKUs. It will not function in AMD-based platforms or older Intel systems without CNVi support. Physically, the card can be inserted into any M.2 Key E slot, but if the host chipset does not provide CNVi, the Wi-Fi will not be recognized. This module also includes Bluetooth 5.0, which connects via a separate USB interface inside the M.2 slot. Supported operating systems are Windows 10 64-bit (primary), Linux (limited), and Chrome OS.

Product Info

The Intel Wireless-AC 9560 was introduced around 2018 and remains a solid mid-range wireless solution within Intel's ecosystem. Its market positioning is entry-to-mid tier, offering reliable 802.11ac connectivity without the cost of Wi-Fi 6. Pricing hovers around ¥5,000 (~$35 USD) from online retailers. Intel typically provides a one-year warranty through its distributors. The module is sold bare (no antenna cables or brackets), so you may need to source antennas separately if they are not already present in your system. Availability is good via and specialty PC parts resellers.

Best Use Cases

This product is ideal for: Laptop Wi-Fi/BT module replacement: If your laptop has a CNVi-compatible Intel CPU and the original module is faulty or outdated (e.g., only Bluetooth 4.x), swapping in the AC 9560 is a cost-effective fix. Be sure to check BIOS whitelist restrictions though — some OEMs lock the Wi-Fi card list. Building a compact desktop (NUC, mini-ITX): Many Intel-based mini-PCs come with CNVi support; installing this module adds fast Wi-Fi and Bluetooth without taking up a PCIe slot. It's a neat solution for home theater PCs or office desktops. * Budget-conscious users who don't need Wi-Fi 6: Everyday browsing, streaming, and light file sharing are well served by the AC 9560. If your router is still 802.11ac, this is a perfect match. It is not suitable for users with non-Intel or older platforms, nor for those seeking the latest Wi-Fi 6/6E speeds. In those cases, consider a PCIe-based module like the Intel AX210.

Product Disclosure (Amazon)

  • Manufacturer: インテル
  • Seller: Greatgearshop
  • Fulfilled by: Greatgearshop
  • ASIN: B07G42J6KQ
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
