This article covers Ubiquiti NanoStation 5AC Loco 5GHz airMAX ac CPE 専用Wi-Fi管理付き (Loco5AC-US).

Overview

The Ubiquiti NanoStation 5AC Loco (model LOCO5AC-US) is a compact outdoor CPE (Customer Premises Equipment) that operates on the 5GHz band with 802.11ac support. It integrates the radio and antenna into a single weather-resistant enclosure, utilizes airMAX TDMA protocol, and offers dedicated Wi-Fi management. With a maximum throughput of 450Mbps and a 16dBi antenna, it excels in point-to-point bridging and last-mile ISP deployments. The unit is lightweight, easy to mount, and powered via passive PoE, making it ideal for outdoor installations where running cable is impractical.

Connectivity & Compatibility

The NanoStation 5AC Loco features a single Gigabit Ethernet port (10/100/1000) that carries both data and power via the included 24V passive PoE injector. Configuration is handled through a web-based interface or the airOS software suite, which is compatible with any modern browser on Windows, macOS, or Linux. Note that this device is designed as a bridge or CPE — it does not include DHCP server or NAT functionality out of the box. You will need an existing router with DHCP and internet access to place it behind. For point-to-point links, a pair of NanoStations is required.

Product Info

Released around 2019, the NanoStation 5AC Loco is still actively produced by Ubiquiti. The street price on Japan is approximately ¥17,600. It comes with a 1-year manufacturer warranty. The package includes the unit, PoE injector, power cable, mounting straps, and quick-start guide. The product sits at the entry-to-mid range of Ubiquiti’s outdoor CPE lineup, offering excellent price-to-performance ratio for long-range wireless links. The integrated 16dBi antenna provides solid gain for distances up to several kilometers under line-of-sight conditions.

Best Use Cases

Extending network between separate buildings — If you need to connect two buildings (e.g., office and warehouse) without trenching or cable runs, a pair of NanoStation 5AC Locos can create a stable wireless bridge over several kilometers, providing full gigabit-speed backhaul. The setup is straightforward: one unit configured as ‘AP’ (Access Point), the other as ‘Station’. Last-mile ISP deployments in rural areas — With airMAX technology and high antenna gain, this device is perfect for ISPs delivering internet to remote homes. It can effectively handle bandwidth demands of multiple users while keeping deployment costs low. * Temporary networking for outdoor events or construction sites — The lightweight design (180g) and simple pole-mount make it easy to set up a temporary link. Just mount on a mast, plug in PoE, and configure. Power consumption is only 8W, so it can run on a small UPS or solar setup. Who should avoid it? Anyone looking for a conventional home Wi-Fi router (wireless access point with NAT/DHCP). This is a pure bridge/CPE — it cannot serve as a standalone router for your home network.

Product Disclosure (Amazon)

  • Manufacturer: Ubiquiti Networks
  • Seller: Re:birth
  • Fulfilled by: Re:birth
  • ASIN: B081VRFK62
  • Note: This article covers a manufacturer-made product based on Amazon listing details.
