Sapphire 11295-01-20G Radeon PULSE RX 5500 XT 8GB GDDR6 HDMI

This article covers Sapphire 11295-01-20G Radeon PULSE RX 5500 XT 8GB GDDR6 HDMI.

Overview

The Sapphire Radeon PULSE RX 5500 XT 8GB is a mid-range graphics card built on AMD's Navi 14 architecture. It features a boost clock of up to 1845 MHz and a game clock of up to 1737 MHz, paired with 8GB of GDDR6 memory. This card is designed for 1080p gaming with a strong emphasis on price-to-performance ratio. With three DisplayPort outputs and one HDMI port, it supports multi-monitor setups out of the box. A backplate is included for PCB protection and improved heat dissipation. PCIe 4.0 support ensures maximum bandwidth when paired with a compatible motherboard. Positioned at the entry-to-mid-range boundary, the RX 5500 XT offers 8GB of VRAM at a competitive price point, making it an excellent choice for budget-conscious gamers who still want solid performance.

Compatibility Guide

PCIe Interface: PCIe 4.0 x8. Works with PCIe 3.0 motherboards, but bandwidth is halved. Real-world gaming impact is minimal, but a PCIe 4.0 board is recommended for best performance. Power Requirements: TDP is approximately 130W. A 450W or higher PSU is recommended by the manufacturer. A single 8-pin PCIe power connector is required. Physical Dimensions: Dual-slot design, approximately 230mm in length. Fits most mid-tower cases, but check clearance for compact builds. Output Ports: DisplayPort 1.4 x3, HDMI 2.0b x1. Supports 4K 60Hz output and multi-monitor configurations.

Product Info

Released in early 2020, the Sapphire PULSE RX 5500 XT 8GB sits at the entry-level end of the mid-range segment. Its 8GB GDDR6 memory is a standout feature at this price tier, preventing VRAM bottlenecks in modern titles. The dual-fan cooler and backplate contribute to stable thermal performance under load.

Best Use Cases

1080p 60fps Gaming: Handles eSports titles like Fortnite, Apex Legends, and Valorant at high settings with ease. AAA games like Cyberpunk 2077 run at medium-high settings around 60fps. Budget PC Builders: Offers excellent value with 8GB VRAM at around $200-250 USD. Ideal for first-time builders or those on a tight budget. Secondary or HTPC Builds: Low power consumption and heat output make it suitable for living room media PCs or secondary gaming rigs. Multi-Monitor Productivity: Four video outputs allow for triple-monitor or 4K monitor setups without additional adapters. Not recommended for 4K high-refresh-rate gaming or heavy ray tracing workloads. For those use cases, consider a higher-tier GPU like the RX 6600 XT or RTX 3060. ## Alternatives
Direct competitors include the NVIDIA GeForce GTX 1660 Super. The RX 5500 XT has an edge in memory bandwidth and PCIe 4.0 support, while the GTX 1660 Super performs slightly better in some DirectX 11 titles and offers NVENC encoding for streamers. Another alternative is the older AMD Radeon RX 580 (8GB). The RX 5500 XT is more power-efficient and has a newer architecture, but the RX 580 can often be found cheaper on the used market.

Things to Consider

PCIe 3.0 Bandwidth: On PCIe 3.0 motherboards, the card runs at x8 speed. Gaming performance impact is typically under 5%, but data-intensive workloads may see a larger drop. Ray Tracing Performance: While the RX 5500 XT supports ray tracing, its limited RT cores mean significant frame rate drops when enabled. For ray tracing, step up to an RX 6000 series card. Availability: As an older model, new stock may be limited. Check retailer inventory carefully before purchasing. Driver Stability: AMD's Adrenalin drivers are regularly updated, but occasional game-specific issues have been reported. Always install the latest drivers after purchase. ## FAQ Q: Can this card handle 4K gaming? A: Lightweight or older titles may run at 4K with medium settings, but modern AAA games will struggle. 1080p or 1440p is the sweet spot for this GPU. Q: What power supply do I need? A: A 450W PSU is the minimum recommendation. A quality 500W unit with an 8-pin PCIe connector is a safe choice for most builds. Q: GTX 1660 Super vs RX 5500 XT — which is better? A: Both are excellent at this price point. The RX 5500 XT offers 8GB VRAM and PCIe 4.0, while the GTX 1660 Super has NVENC and slightly better performance in some games. Choose based on your specific needs (streaming vs. VRAM capacity).
