Hanye 1TB 内蔵型SSD 2.5インチ 7mm SATAIII 6Gb

This article covers Hanye 1TB 内蔵型SSD 2.5インチ 7mm SATAIII 6Gb.

Overview

The Hanye Q55-1TSY04 is a SATA III 2.5-inch SSD with 1TB capacity, sold as a 2-pack. Each drive delivers sequential read speeds up to 550 MB/s and writes up to 500 MB/s, powered by 3D NAND flash. The slim 7mm height makes it compatible with most laptops and desktops, while the aluminum housing improves heat dissipation and durability. With an effective price of roughly ¥20,800 per unit, this bundle appeals to users who need multiple drives for upgrades or new builds. The official Japanese distributor provides a 3-year warranty, adding peace of mind for buyers unfamiliar with SSD installation. Positioning itself firmly in the entry-to-mid-range segment, it offers a cost-effective way to breathe new life into older systems still relying on SATA connections.

Compatibility Guide

The drive uses the standard 2.5-inch form factor with 7mm thickness, fitting natively into virtually any modern laptop or desktop 2.5-inch bay. It connects via SATA III (6Gbps) and is backward compatible with SATA II (3Gbps) ports, though performance will cap at the slower interface speed. Power is drawn from a standard SATA power connector, so no special adapter is needed for desktop builds. In laptops, verify that the drive bay supports 7mm height --- some older models require 9.5mm drives or a spacer. The SSD ships uninitialized; after physical installation, users must create a partition and format it using Disk Management (Windows) or Disk Utility (macOS). For OS installation, the boot order in BIOS/UEFI must also be adjusted.

Product Info

Model number: Q55-1TSY04. Capacity: 1TB (user-accessible ~953GB). Interface: SATA III 6Gbps. Sequential read: up to 550 MB/s; sequential write: up to 500 MB/s. NAND type: 3D NAND (vendor unspecified). Controller and DRAM cache presence are not disclosed --- it is likely a DRAM-less design given the price point. The aluminum enclosure adds strength and aids heat dissipation. Weight per drive is approximately 140g. Warranty: 3 years or 320 TBW, whichever comes first. Market positioning: entry to mid-range. It prioritizes affordability and capacity over raw speed, making it ideal for HDD replacement, secondary storage, or RAID builds where SATA is the limiting factor.

Best Use Cases

HDD upgrade for a legacy PC: If you are still running a mechanical hard drive, swapping in this SSD will dramatically improve boot times and application loading. The 2-pack lets you upgrade both your main PC and a secondary system simultaneously. Laptop storage expansion: Removing the optical drive to install a second 2.5-inch SSD is a common upgrade. The 7mm profile fits most optical bay caddies, giving you affordable extra space for documents, games, or media. * RAID 0 configuration: With two identical SSDs, you can configure a software or hardware RAID 0 array to double sequential throughput. However, be aware of the increased failure risk and lack of redundancy. Not recommended for: users who need NVMe-level speeds for large file transfers, 4K video editing, or AAA game loading. Also not ideal for write-heavy workloads like surveillance recording, given the TBW limit of 320TB per drive. ## Alternatives
Direct competitors include the Crucial BX500 1TB and Kingston A400 1TB. All three offer similar sequential speeds (540--550 MB/s) and SATA interface. The Hanye differentiator is the 2-pack value; per-unit cost is lower than buying two singles from Crucial or Kingston. However, the latter brands have longer track records and more comprehensive compatibility lists, which may matter for mission-critical systems. For those with an available M.2 slot, upgrading to a PCIe Gen3 NVMe SSD (e.g., WD Blue SN580 or Samsung 980) delivers roughly 10x faster sequential performance. The price premium is modest, making NVMe a better choice if motherboard compatibility allows.

Things to Consider

Because it ships as a 2-pack, you must need two drives to get the best value. If only one drive is required, a single-pack from another brand may be more economical. The drives are uninitialized, so you must manually partition and format each one before use --- this is straightforward but may trip up beginners. Windows does not assign a drive letter automatically, so you must open Disk Management. The TBW rating of 320TB translates to roughly 0.87 years of continuous writing at 1TB/day, but typical home use (20--50GB/day) would take 6--17 years to exhaust the limit. The 3-year warranty period is the more likely expiry date. Note that DRAM-cacheless design may cause lower random write performance compared to DRAM-equipped SSDs like the Samsung 870 EVO. This is unlikely to be noticeable in everyday tasks but can affect small-file workloads. ## FAQ Q: Can I use this SSD in a PS4 or PS5? A: Yes, PS4 supports 2.5-inch SATA SSDs up to 9.5mm --- the 7mm thickness fits without issue. PS5 requires M.2 NVMe for internal storage, but this drive can be used as external USB
